A36

Reflect the pride
of a life well-lived.

Design Yours
COBALT A36

A Crossover of Deluxe Luxury and Contemporary Design

ACTIVITIES
  • Day Cruising
  • At Anchor In-Water Activity
  • Overnight Aboard
Environment
  • Large Bodies of Water
Trailering
  • No
LOA
35' 11"
Beam
11' 2"
Fuel
189 gal
Capacity
yacht certified
Head
yes

Exterior

The A36 combines the comforts of a coupe-top design with the practical features of a bowrider. This flagship model has the handling characteristics of a runabout with the length, beam, and comfortable ride of a yacht.
Hydraulic Swim Platform

Great for water activities, the entire full-width swim platform lowers below the water hydraulically with the push of a button, offering easy access in or out of the water and into the boat.

Bow Lounge

Enjoy large spacious, smooth flat cushion for lounging and shallow depth allows more cabin headroom below.

Cobalt Deep V- Hull

Provides a smooth and stable ride in rougher water, very responsive in turns with effortless handling.

Features & Innovations

Interior Innovation

Fresco Chil Vinyl

Finally, no more hot seats on darker colored vinyl while you’re out enjoying a full day of fun on the water. This anti-bacterial, anti-fungal, mildew-resistant, and sulfide stain-resistant fabric technology keeps your vinyl a full 15-20 degrees cooler than traditional vinyl even when it’s out in the sun.
Step & Platform Innovation

SOF-TRAC POSITIVE TRACTION MAT

Dress up your swim platform with the Sof-Trac Positive Traction Mat. Gentle on swimsuits and wakeboards, you’ll maintain traction even when wet. Dealer-installed kits are available for most current models with or without the Swim Step.

Interior Feature

Cobalt + Garmin

The Cobalt Glass Cockpit System is the premier multi-display solution for total helm control. The Garmin interface is fully integrated with the most pivotal handling and safety information from your Cobalt powertrain. The result is the ultimate boating experience now available with larger screens on select Cobalt models.
Exterior Feature

Fender Clip Package

The Cobalt stainless-steel fender clips are a quick mount system installed in the deck at the perfect fender position, so the lines are always set to optimum length. When docking, simply insert the pin into the fitting and you’re done.

Interior

Featuring a fully equipped cabin with a forward berth—plus cabin seating that converts to a full-length berth—the A36’s hybrid cabin layout is ideal for a range of family activities on the water. Beautiful, comfortable, and ruggedly built, the A36 sets the standard for luxury boating.
Aft-Facing Rumble Seat

Simply operated, offers seating on the sunpad at the swim platform, keeping you near the in-water activity on the platform. When not in use, folds down flat to become hidden in the sunpad.

Cabin

Spacious with seating and forward V-berth, plus a hybrid design buddy cabin and above-deck exterior bow lounge. Find a tinted skylight and side window, fine wood upper cabinetry, and more.

Aft Backrest

Adjustable to 2 positions—face forward/face aft—with wide, independently adjustable split backrest, plus stainless-steel handle for added security in rough waters and steel hinge mechanism.

Technical Details

  • Length Overall w/Swim Platform
    35' 11'' / 10.95 m
  • Beam
    11' 2'' / 3.40 m
  • Interior Cockpit Width
    110'' / 2.79 m
  • Deadrise at Transom
    22º / 22º
  • Fuel Capacity - Gasoline
    189 gal. / 715 L
  • Freshwater Capacity
    27 gal. / 102 L
  • Holding Tank Capacity
    10 gal. / 38 L
  • Bridge Clearance
    9' 1'' / 2.77 m
  • Draft Drive Up
    31'' / .78 m
  • Draft Drive Down
    42'' / 1.07 m
  • Dry Weight (varies with options)
    16000 / 7,257 kg
  • Boat Certified Capacity
    Yacht Certified
  • Boat Certified Capacity w/gear
    Yacht Certified

Volvo Penta

  • Twin V8-380CE DP - 380 hp (283 PkW)
  • Twin V8-430CE DP - 430 hp (321 PkW)

Engine Enhancements (Standard)

  • EVC w/PTA & Cruise (Volvo)
  • Trip Computer (Volvo EVC)

Engine Enhancements (Optional)

  • Autopilot (Volvo)
  • Joystick Sterndrive w/E Key (Volvo)
  • Ocean-X (Volvo) - Detail
    Ocean-X (Volvo)

    Ocean-X (Volvo)

    Ocean X (Salt Water Ready) Duoprop Outdrive Packages with Fresh Water Cooling Protected by a revolutionary titanium-ceramic coating and new sensor technology, OceanX is Volvo Penta's answer to the corrosive effects of salt water.

Standard

  • Compass, Digital
  • Depth & Water Temp Pkg.
  • Digital Spyder Controls
  • Glass Cockpit w/Garmin 8612
  • Steering Wheel, Leather Color-Matched
  • Windshield Wiper, Stbd.

Optional

  • Autopilot (Volvo)
  • Joystick Sterndrive w/E Key (Volvo)
  • Ocean-X (Volvo) - Detail
    Ocean-X (Volvo)

    Ocean-X (Volvo)

    Ocean X (Salt Water Ready) Duoprop Outdrive Packages with Fresh Water Cooling Protected by a revolutionary titanium-ceramic coating and new sensor technology, OceanX is Volvo Penta's answer to the corrosive effects of salt water.

Standard

  • Custom Acoustic Speaker Covers
  • iPod/USB/MP3 Port - Detail
    Includes USB-A and USB-C connections.  Multiple power ports throughout, and one power/data port at helm.

    iPod/USB/MP3 Port

    Includes USB-A and USB-C connections. Multiple power ports throughout, and one power/data port at helm.

  • Premium Sound System w/Transom Remote & Spkrs.
  • Stereo Remote, Dash

Optional

  • Cabin Entertainment Package (TV/DVD)
  • KVH (Coastal)
  • KVH (Inland)
  • Platinum Sound System
  • Satellite Radio System
  • Satellite Weather System
  • TV Antenna & Cable Hook-Up
  • TV w/Lift, Cockpit

Standard

  • Cabin Skylights
  • Cabinetry, Gray Driftwood
  • Fiberglass Liner w/Sea Grass Floor Cover - Detail
    Fiberglass Liner w/Sea Grass Floor Cover

    Fiberglass Liner w/Sea Grass Floor Cover

  • Head w/Sink & VacuFlush Toilet - Detail
    Head w/Sink & VacuFlush Toilet

    Head w/Sink & VacuFlush Toilet

  • Integrated Cabin Filler Cushion
  • LED Overhead Lighting, Cabin
  • Panoramic Cabin Windows
  • Suspended Cabin Headliner

Optional

  • Air Conditioning/Heat Self-Prime
  • Air Conditioning/Heating
  • Floor, Teak (Bow, Cockpit, Walk-Thru)
  • Gray Water System
  • Head w/VacuFlush, Macerator - Detail
    Head w/VacuFlush, Macerator

    Head w/VacuFlush, Macerator

  • LED Interior Accent Lighting (RGB) - Detail
    LED Interior Accent Lighting (RGB)

    LED Interior Accent Lighting (RGB)

    (Shown in Cobalt model R6)

  • Remote Courtesy Lights w/key fob
  • Throw Pillows, Weighted (10) - Detail
    Throw Pillows, Weighted (10)

    Throw Pillows, Weighted (10)

    Pillows are filled with 4 pounds of Vyram weighted pellets for stable placement while boat is underway. Available in five Sunbrella outdoor fabric colors. Size: 22 x 22 inches.

  • Throw Pillows, Weighted (4) - Detail
    Throw Pillows, Weighted (4)

    Throw Pillows, Weighted (4)

    Pillows are filled with 4 pounds of Vyram weighted pellets for stable placement while boat is underway. Available in five Sunbrella outdoor fabric colors. Size: 22 x 22 inches.

Standard

  • Bow Rails, Stainless Steel
  • Dinette Table, Cockpit - Detail
    Dinette Table, Cockpit

    Dinette Table, Cockpit

  • Direct Bond Edge-Style Windshield
  • Fender Clips w/Line (6) - Detail
    Fender Clips w/Line (6)

    Fender Clips w/Line (6)

    A set of Custom Stainless Fender Clips, which provide a solid and secure place to hang the fenders. Includes the insert, the receptacle, and fender lines.

  • Foredeck Sunpad Filler Cushion Set
  • LED Lighting & Dual Spkrs., Coupe Top
  • Motorbox Actuator, Electric
  • Snap-In Carpet, Cockpit
  • Stainless Steel Cupholders
  • Swim Platform w/Ladder, Hydraulic
  • Transhield Shipping Cover
  • Transom Storage Locker(s)

Optional

  • Barbeque Grill, Cockpit - Detail
    Barbeque Grill ,Cockpit

    Barbeque Grill, Cockpit

  • COBALT Lettering, Satin Black (exterior) - Detail
    COBALT Lettering, Satin Black (exterior)

    COBALT Lettering, Satin Black (exterior)

  • Cockpit Seat, Stbd.
  • Coupe Top w/LED Lighting (std)
  • Docking Lights-Stainless Steel - Detail
    Docking Lights-Stainless Steel

    Docking Lights-Stainless Steel

  • Equipment Shelf (Coupe mounted)
  • Flagpole w/Flag - Detail
    Flagpole w/Flag

    Flagpole w/Flag

    Stainless steel flag pole with flag clips, receptacle and flag.

  • Floor Covering, Sea Grass-Cockpit - Detail
    Floor Covering, Sea Grass-Cockpit

    Floor Covering, Sea Grass-Cockpit

    Sea Grass floor covering creates an elegant and comfortable style to the interior of any Cobalt. Rubber backing and stainless steel snaps make it as durable as it is elegant.

  • Fresh Water Washdown, Bow
  • Galley w/Sink, Cockpit (replaces seat) - Detail
    Galley w/Sink, Cockpit (replaces seat)

    Galley w/Sink, Cockpit (replaces seat)

    Optional barbecue grill also shown.

  • Refrigerator, Cockpit - Detail
    Refrigerator, Cockpit

    Refrigerator, Cockpit

    Installation varies depending on boat model and other options.

  • Sof-Trac Mat, Cockpit - Detail
    Sof-Trac Mat, Cockpit

    Sof-Trac Mat, Cockpit

    Sof-Trac platform mat combines an aggressive non-skid traction with the soft feel of a cushioned pad. Durable and stylish, the sof-trac mat is a water sport enthusiast favorite. (shown in model R8)

  • Sof-Trac Mat, Swim Platform
  • Spotlight, Remote - Detail
    Spotlight, Remote

    Spotlight, Remote

  • Swim Platform Transom Lighting
  • Teak Swim Platform
  • Transom Shower - Detail
    Transom Shower

    Transom Shower

    Freshwater wash down with pressure water system and fresh water tank.

  • Transom Tilt Switches (twin) - Detail
    Transom Tilt Switches (twin)

    Transom Tilt Switches (twin)

    Control the drive trim adjustment at the transom for utilization while trailering or dockside.

  • Underwater Lighting - Detail
    Underwater Lighting

    Underwater Lighting

    LED underwater lighting system includes two light pods and the switch module. Beautiful evenings begin with illumination. Shown on model 302. Swim platform transom lighting also shown.

Optional

  • Electric Sureshade
  • Full Canvas Enclosure Package - Detail
    Full Canvas Enclosure Package

    Full Canvas Enclosure Package

Standard

  • 10/5/3 Year Warranty Protection
  • Battery Charger, 60 amp
  • CO Monitor
  • Composite Floor
  • Composite Transom
  • Fiberglass Cockpit Liner
  • Fiberglass Stringer System
  • Fire Extinguisher(s), Manual
  • Galvanic Protection
  • Ignition Safety Switch - Detail
    Ignition Safety Switch

    Ignition Safety Switch

    Standard engine ignition safety switch with belt clip.

  • Kevlar Reinforced Hull
  • Shorepower-110v, Dual 30 amp
  • Tool Kit - Detail
    Tool Kit

    Tool Kit

  • Trim Tabs, Electric w/Autoglide System - Detail
    Trim Tabs, Electric w/Autoglide System

    Trim Tabs, Electric w/Autoglide System

  • Windlass, All Chain w/Anchor - Detail
    Windlass, All Chain w/Anchor

    Windlass, All Chain w/Anchor

    Recessed anchor windlass is mounted below decks in the anchor locker. Cobalt uses a through hull mounted hause pipe made of stainless steel, and a stainless delta style anchor with 125 feet of chain and plaited line. Installation may vary depending on specific boat model.

Optional

  • Captain's Call Exhaust-twin
  • CE Requirements
  • Chain Counter for std. Windlass - Detail
    Chain Counter for std. Windlass

    Chain Counter for std. Windlass

    Recessed anchor windlass is mounted below decks in the anchor locker. Cobalt uses a through hull mounted hause pipe made of stainless steel, and a stainless delta style anchor with 125 feet of chain and plaited line. Installation may vary depending on specific boat model.

  • Fire Extinguisher, Automatic System - Detail
    Fire Extinguisher, Automatic System

    Fire Extinguisher, Automatic System

    Heat sensitive automatic Fireboy system mounted in the engine compartment designed to instantly eliminate flames in the event of an engine fire. Installation will vary depending on specific boat model.

  • Generator (Gas) 6.5kW
  • Shorepower-220v, Dual 30 amp
