A36BR

A36BR
With deeper, more spacious bow seating than ever before, the all new A36BR combines the coupe-top design and popular appearance of the A-Series, but adds additional seating and a more ergonomical cockpit. The A36BR maintains its high-end, roomy feel with a cabin featuring a hidden filler cushion that folds down to create a sleeping surface for two, just another way Cobalt is once again extending the luxury boating experience.
LOA:
Beam:
Seating Capacity:
Dry Weight:
Technical Details
Length Overall w/Swim Platform | 35' 11'' | 10.95 m |
Beam | 11' 2'' | 3.40 m |
Interior Cockpit Width | 110'' | 2.79 m |
Deadrise at Transom | 22º | 22º |
Fuel Capacity - Gasoline | 189 gal. | 715 L |
Freshwater Capacity | 27 gal. | 102 L |
Holding Tank Capacity | 10 gal. | 38 L |
Bridge Clearance | 9' 1'' | 2.77 m |
Draft Drive Up | 31'' | .78 m |
Draft Drive Down | 42'' | 1.07 m |
Dry Weight | 16000 | 7,257 kg |
Boat Certified Capacity | Yacht Certified | |
Boat Certified Capacity w/gear | Yacht Certified |
A36BR Volvo Penta Power Selections
- Twin V8-380CE DP - 380 hp (283 PkW)
- Twin V8-430CE DP - 430 hp (321 PkW)
A36BR Engine Enhancements - Standard
- Active Corrosion Protection
- EVC w/PTA & Cruise (Volvo)
- Trip Computer (Volvo EVC)
A36BR Engine Enhancements - Optional
- Autopilot (Volvo)
- Joystick Sterndrive w/E Key (Volvo)
- Ocean-X (Volvo)
A36BR Dash and Instrumentation - Standard
- Compass, Digital
- Depth & Water Temp Pkg.
- Digital Spyder Controls
- Glass Cockpit, Garmin 7612
- Premium Black Leather/SS Steering Wheel
A36BR Entertainment System - Standard
- Custom Acoustic Speaker Covers
- iPod/USB/MP3 Port
- Premium Sound System w/Transom Remote & Spkrs.
- Stereo Remote, Dash
A36BR Interior - Standard
- Cabin Skylights
- Cabinetry, Gray Driftwood
- Fiberglass Liner w/Sea Grass Floor Cover
- Head w/Sink & VacuFlush Toilet
- Integrated Cabin Filler Cushion
- LED Overhead Lighting, Cabin
- Panoramic Cabin Windows
- Suspended Cabin Headliner
A36BR Exterior - Standard
- Bow Rails, Stainless Steel
- Dinette Table, Cockpit
- Direct Bond Edge-Style Windshield
- Fender Clips w/Line (6) Detailx
Fender Clips w/Line (6)
A set of Custom Stainless Fender Clips, which provide a solid and secure place to hang the fenders. Includes the insert, the receptacle, and fender lines.
- Hard Top Sunroof
- Motorbox Actuator, Electric
- Snap-In Carpet, Cockpit
- Stainless Steel Cupholders
- Swim Platform w/Ladder, Hydraulic
- Transhield Shipping Cover
- Transom Storage Locker(s)
A36BR Structure and Safety - Standard
- 10/5/3 Year Warranty Protection
- Battery Charger, 60 amp
- CO Monitor
- Composite Floor
- Composite Transom
- Fiberglass Cockpit Liner
- Fiberglass Stringer System
- Fire Extinguisher(s), Manual
- Galvanic Protection
- Ignition Safety Switch Detail
- Kevlar Reinforced Hull
- Shorepower-110v, Dual 30 amp
- Tool Kit Detail
- Trim Tabs, Electric w/Autoglide System
- Windlass, All Chain w/Anchor Detailx
Windlass, All Chain w/Anchor
Recessed anchor windlass is mounted below decks in the anchor locker. Cobalt uses a through hull mounted hause pipe made of stainless steel, and a stainless delta style anchor with 125 feet of chain and plaited line. Installation may vary depending on specific boat model.
A36BR Canvas - Optional
- Bow Tonneau Cover
- Electric Sureshade
- Full Canvas Enclosure Package
- Shade Sail, Bow
A36BR Dash and Instrumentation - Optional
- Compass, Magnetic
- Glass Cockpit w/16'' Dual Screen Upgrade
- VHF Radio w/Antenna
- Windshield Wiper, Stbd.
- Radar, Garmin 24'' HD Dome w/KVH & Shelf
- Radar, Garmin 24'' HD Dome w/Shelf
- Radar, Garmin 48'' Open Array w/KVH & Sh
- Radar, Garmin 48'' Open Array w/Shelf
A36BR Entertainment System - Optional
- Cabin Entertainment Package (TV/DVD)
- Platinum Sound System
- Satellite Radio System
- Satellite TV (Coastal)
- Satellite TV (Inland)
- Satellite Weather System
- TV Antenna & Cable Hook-Up
- TV w/Lift, Cockpit
A36BR Interior - Optional
- Air Conditioning/Heat Self-Prime
- Air Conditioning/Heating
- Floor, Teak (Bow, Cockpit, Walk-Thru)
- Gray Water System
- Head w/VacuFlush, Macerator
- LED Interior Accent Lighting (RGB)
- Remote Courtesy Lights w/key fob
- Throw Pillows, Weighted (10) Detailx
Throw Pillows, Weighted (10)
Pillows are filled with 4 pounds of Vyram weighted pellets for stable placement while boat is underway. Available in five Sunbrella outdoor fabric colors. Size: 22 x 22 inches.
- Throw Pillows, Weighted (4) Detailx
Throw Pillows, Weighted (4)
Pillows are filled with 4 pounds of Vyram weighted pellets for stable placement while boat is underway. Available in five Sunbrella outdoor fabric colors. Size: 22 x 22 inches.
A36BR Exterior - Optional
- Barbeque Grill, Cockpit (w/Galley only)
- Bow Entertainment Pkg.
- Bow Port Console Armret
- Docking Lights-Stainless Steel
- Equipment Shelf (Hardtop mounted)
- Flagpole w/Flag Detailx
Flagpole w/Flag
Stainless steel flag pole with flag clips, receptacle and flag. Shown on model 232 with arch.
- Floor Covering, Sea Grass-Cockpit
- Fresh Water Washdown, Bow
- Galley w/Sink, Cockpit
- Hard Top Sliding Hatch (manual)
- Hard Top w/LED Tri-Color Lighting
- Refrigerator, Cockpit
- Sof-Trac Mat, Cockpit
- Sof-Trac Mat, Swim Platform
- Spotlight, Remote
- Swim Platform Transom Lighting
- Transom Shower
- Transom Tilt Switches (twin)
- Underwater Lighting
- Cockpit Seat, Stbd.
- Teak Swim Platform
A36BR Structure and Safety - Optional
- Captain's Call Exhaust-twin
- CE Requirements
- Chain Counter for Std. Windlass
- Fire Extinguisher, Automatic System
- Generator (Gas) 6.5kW
- Shorepower-220v, Dual 30 amp



Only A Cobalt
Since its first day on the water over 50 years ago, Cobalt’s commitment to performance, luxury and innovation has continued to set the standard for boating excellence. Only a Cobalt offers:
- Hydraulic swim platform
- Maximum interior space
- 21-layer hand-laid fiberglass at keel
- Deep-V hull design for smooth ride
- Double French-stitched interiors
- Molded-in gelcoat graphics
- Extended running surface
